Federal Pacific (FPE) Panel Replacement in South Orange County
Federal Pacific Stab-Lok breakers have a documented history of failing to trip, which can let wiring overheat. We replace the whole panel with a clean, code-compliant one, and right now you get $500 off a 200-amp upgrade.
What a Federal Pacific (FPE) Panel Is
Federal Pacific Electric, usually shortened to FPE, made the Stab-Lok line of electrical panels and breakers that went into homes from roughly the 1950s into the early 1980s. If your South Orange County home was built or re-paneled in that window, there is a real chance the gray panel on your garage wall or side yard is one of them.
The panel itself looks ordinary. What sets it apart is the breaker design, which independent testing later found can fail to trip the way a breaker is supposed to. That is the reason FPE panels get singled out for replacement when most older panels just need a routine upgrade.
How to Tell If You Have a Federal Pacific Panel
You can usually confirm an FPE panel without touching anything live. Look for the words "Federal Pacific Electric," "FPE," or "Stab-Lok" printed on the panel face, on the inside of the cover door, or on a small label sitting between the two rows of breakers near the top. The fastest visual cue homeowners spot is a thin red strip running across the front of each breaker handle. Red handles are a strong hint, though not every red breaker is an FPE, so the printed label is what settles it.
Please do not pull the breakers or remove the panel cover to check. An energized panel is no place to go poking around. If you are not sure what you are looking at, snap a photo of the label and the breaker rows and send it to us, and we will tell you for free what you have.
Book a free on-site assessment. We give you a flat-rate price in writing, with no obligation.
Why Federal Pacific Panels Are a Fire Hazard
The concern with FPE Stab-Lok is not normal wear. It is a design and calibration flaw that independent testing flagged decades ago, where breakers can fail to trip under an overload or short. When a breaker does not trip, the circuit it is supposed to protect can keep heating up.
- Breakers that fail to tripMultiple independent test programs from the late 1970s and early 1980s found Stab-Lok breakers failing to trip at rates that ranged from about a quarter under modest load to well over half under certain overcurrent conditions, depending on how they were tested.
- Heat with nowhere to goA breaker that will not trip lets an overloaded wire keep drawing current, which can overheat the insulation and, in a worst case, ignite nearby combustibles inside the wall or panel.
- A UL listing the courts called deceptiveIt was later established that FPE obtained its UL listing through deceptive practices, and a 2002 New Jersey court found the company knowingly distributed breakers that were not actually tested to the UL standard shown on the label.
- No reliable way to spot a bad breakerBecause the flaw is internal, no electrician or inspector can tell which specific breakers in a given panel are defective without lab testing they are not equipped to do, so the whole panel is treated as suspect.
What a Federal Pacific Panel Means for Insurance and Resale
The most common reason South Orange County homeowners call us about an FPE panel today is insurance. California carriers are increasingly non-renewing or refusing to write policies on homes with Federal Pacific or Stab-Lok panels, and some will only renew if the panel is replaced. That same panel can stall an escrow or get flagged during a buyer's inspection, which holds up a sale at the worst possible moment.
California also passed SB 382, a seller-disclosure law that took effect for home sales on or after January 1, 2026. It does not name Federal Pacific or any brand and it does not require you to replace a panel. What it does is tell sellers to advise buyers to have a qualified pro inspect the service panel and wiring, noting that substandard or faulty wiring can be a fire risk and can make insurance hard to get. In practice that means an FPE panel is now far more likely to surface and become a sticking point at the point of sale. We break down the whole insurance angle in our guide on why insurers keep flagging FPE and Zinsco panels.
Can a Federal Pacific Panel Be Repaired?
No. Swapping in new breakers does not fix it, because the problem lives in the panel's core bus and breaker design rather than in worn-out parts. Replacement Stab-Lok breakers are unproven and may carry the same flaw, and testing has shown them to be about as unreliable as the originals. The insurer and industry consensus is the same one we follow, which is to replace the entire panel regardless of the model number or the year it was made.
What We Replace Your Federal Pacific Panel With
We take the FPE panel out and install a clean, modern, UL-listed panel built around dependable breakers that trip when they are supposed to. It is sized for how your home actually uses power today, with room for an EV charger or solar down the road, and it is wired to current California code. If you want to compare the breaker brands we install, our breakdown of Square D QO versus Homeline is a good place to start, or see the full scope on our panel replacement page.
Our Federal Pacific Panel Replacement Process
We look at your panel, your service, and your wiring, then give you one flat price in writing with no hourly surprises.
Your city or county Building and Safety department requires an electrical permit for this work, and we file it for you, whether you are in Mission Viejo, Lake Forest, San Clemente, or anywhere else in South OC.
Southern California Edison now needs the account holder to authorize the meter pull and reconnect, so we walk you through the one quick call to SCE and handle everything else around it.
A straightforward FPE to new 200-amp swap is usually a same-day job, though a full service upgrade or heavier code work can run a bit longer.
After the install, the local inspector signs off on the work, and we schedule and meet that inspection so power comes back on cleanly under permit.
What Federal Pacific Panel Replacement Costs
FPE replacement covers a wide range because every panel, service, and home is different, so the only number that means anything is the free flat-rate quote we put in writing.
- Panel size and amperage, since moving from 100A to 200A adds work and cost over a like-for-like swap
- Overhead versus underground service, which changes how the wiring comes into the panel
- A combination meter-main, which is more involved than a panel by itself
- Relocating the panel, plus any drywall or stucco patching that comes with it
- Long conductor runs or hard-to-reach panels behind finished walls
- Permit fees and the SCE meter coordination for your specific city or unincorporated area
- Code-triggered upgrades on an older home, such as grounding and bonding, AFCI or GFCI protection, surge protection, and any sub-panels or EV and solar additions
We offer financing so you can spread the cost out, and right now you also get $500 off a 200-amp upgrade.
Federal Pacific Panels in South Orange County Homes
South Orange County is full of homes from the FPE era, the 1960s through the early 1980s tracts across Mission Viejo, Laguna Niguel, Lake Forest, Dana Point, San Clemente, and the older pockets of Irvine and Newport Beach. Plenty of these houses still have their original panel, which means a lot of owners have an FPE on the wall and have no idea. If you are not sure, that red stripe on the breaker handles is the tell, and we cover every city in South OC.
CSLB #1084610
panels are all we do
from South OC homeowners
SCE territory specialists
Frequently Asked Questions
Was there ever a recall on Federal Pacific panels
No, and we will not tell you there was. The CPSC investigated FPE breakers in the early 1980s and closed its case in 1983, saying it could not link the failures to a hazard at that time and that it lacked the funding and data to fully resolve the question. There was no formal recall. The reasons to replace come from decades of independent testing and a 2002 court fraud finding about the UL labeling, not from a recall.
Does California require me to replace an FPE panel
No. SB 382, effective for sales on or after January 1, 2026, is a seller-disclosure law. It does not name Federal Pacific, does not require replacement, and sets no deadline. What is really pushing replacement is insurance carriers non-renewing these homes and buyers flagging the panel during a sale.
Can you just replace the bad breakers instead of the whole panel
No, and we would not recommend it if we could. The flaw is in the panel's core design, and replacement Stab-Lok breakers test about as unreliably as the originals. The clean fix that satisfies insurers and inspectors is a full panel replacement.
What about a Federal Pioneer label instead of FPE
Federal Pioneer is the Canadian-market version of the same Stab-Lok technology, so it carries the same fail-to-trip flaw and comparable test results. It is less common here than FPE, but if you spot a Federal Pioneer label in a South OC home, treat it exactly the same way and have it replaced.
How long does the replacement take
Most straightforward 200-amp FPE replacements are finished in a day, often in a four to eight hour window. A bigger service upgrade or extra code-required work can push it to a full day or a little longer, and we will tell you which one yours is in the written quote.
Do you handle the permit and the SCE meter
Yes. We pull the electrical permit with your local OC building department and coordinate the SCE meter release and reconnect. Edison now needs you, the account holder, to make the authorizing call, so we walk you through that one quick step and handle the rest, including meeting the final inspection.
